Nozzle color/Diameter | 1.0mm | 1.2mm | 1.4mm | 1.6mm | 1.8mm | 2.0mm | ||||||
Water Pressure(bar) | Folw(L/H) | Radius(m) | Folw(L/H) | Radius(m) | Folw(L/H) | Radius(m) | Folw(L/H) | Radius(m) | Folw(L/H) | Radius(m) | Folw(L/H) | Radius(m) |
1.5 | 37.8 | 1.8 | 53.9 | 1.8 | 72.8 | 1.9 | 90 | 2.1 | 115.8 | 2.2 | 147.9 | 2.2 |
2.0 | 45 | 2.0 | 64.4 | 2.0 | 86.1 | 2.0 | 105.6 | 2.2 | 136.7 | 2.4 | 175 | 2.4 |
2.5 | 51.1 | 00 0 |
73.3 | 2.0 | 97.8 | 2.2 | 116.1 | 2.3 | 150 | 2.4 | 197.5 | 2.5 |
3.0 | 55.6 | 2.2 | 79.4 | 2.2 | 107.2 | 2.3 | 125 | 2.5 | 162.5 | 2.6 | 221.7 | 2.6 |
